| PartNumber | SN270CS01-1 |
| Marca | HKC |
| mărimea | 27.0 |
| Aplicație | Desktop Monitor |
| Rezoluţie | 1920×1080 |
| Compoziţie | CELL, a-Si TFT-LCD |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | No |
| Interfață | LVDS |
| producător | HKC |
| numele modelului | SN270CS01-1 |
| marimea ecranului | 27.0 inch |
| tipul de ecran | CELL, a-Si TFT-LCD |
| numărul de pixeli | 1920(RGB)×1080 (FHD) 81PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 597.888 × 336.312 (H×V) |
| contur (mm) | 606.088 × 349.212 × 1.27 (H×V×D) |
| zona rama (mm) | - |
| tratament | Antiglare (Haze 25%), Hard coating (3H) |
| luminanţă | 0 cd/m² |
| Raport de contrast | 1000 : 1 (Typ.) (TM) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10) |
| raspuns | 14 (Typ.)(G to G) ms |
| vedere buna la | Symmetry |
| modul de lucru | HIS, Normally Black, Transmissive |
| grosimea sticlei | 0.50+0.50 mm |
| transmisivitatea | 5.7% (Typ.) |
| adâncimea culorii | 16.7M 72% NTSC |
| lumina de fundal | No B/L |
| masa | 670g (Typ.) |
| folosit pentru | Desktop Monitor |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| lista de drivere ic | Built-in COF 8 source chips |
| tipul semnalului | LVDS (2 ch, 8-bit) , Connector 30 pins |
| alimentare cu tensiune | 5.0V (Typ.) |
| max. evaluări | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
