| PartNumber | LTM270DL06 |
| Marca | Samsung |
| mărimea | 27.0 |
| Aplicație | DMPC |
| Rezoluţie | 2560×1440 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | SAMSUNG |
| model de panou | LTM270DL06 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 27.0 inch |
| rezoluţie | 2560(RGB)×1440 , Quad-HD |
| modul de afișare | PLS, Normally Black, Transmissive |
| Zonă activă | 596.736×335.664 mm |
| contur | 630×368.2×16.1 mm |
| suprafaţă | Antiglare (Haze 35%), Hard coating (3H) |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), sRGB |
| timp de raspuns | 12 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 16S4PWLEDWithout Driver |
| interfață de semnal | LVDS (4 ch, 8-bit), 61 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | DMPC |
