| PartNumber | PW070DS1T1 |
| Marca | E Ink |
| mărimea | 7.0 |
| Aplicație | VDP |
| Rezoluţie | 480×234 |
| Compoziţie | LCM |
| Luminozitate | 350 |
| CR | 150:1 |
| Culori | |
| Iluminare de fundal | CCFL |
| Interfață | Analog |
| marca panoului | PVI |
| model de panou | PW070DS1T1 3 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 480(RGB)×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 154.08×87.05 mm |
| contur | 166.9×101.8 mm |
| suprafaţă | Antiglare, Hard coating |
| luminozitatea | 350 cd/m² (Typ.) |
| Raport de contrast | 150:1 (Typ.) |
| culorile afișajului | |
| timp de raspuns | 30/50 (Max.)(Tr/Td) |
| unghi de vedere | 55/55/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | Analog RGB + Composite Video (NTSC/PAL), 30 pins |
| tensiune de intrare | 3.3/5.0/17/-12V (Typ.)(VCC/VDD/VGON/VGOFF) |
| rohs: | |
| aplicarea | VDP |
| AM-800480RSTMQW-TA1H | AMPIRE | 7.0 | 800×480 |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| LQ070T5DR01 | SHARP | 7.0 | 480×240 |
| PM070WL3 | E Ink | 7.0 | 800×480 |
| PW070DS1T1 | E Ink | 7.0 | 480×234 |
| PW070DS1T2 | E Ink | 7.0 | 480×234 |
| PW070DS1T6 | E Ink | 7.0 | 480×234 |
| PW070NS1W2 | E Ink | 7.0 | 480×320 |
| PW070XU3 | E Ink | 7.0 | 480×234 |
| PW070XUA | E Ink | 7.0 | 480×234 |
| A040CN01 V2 | AUO | 4.0 | 480×234 |
| A056DN01 | AUO | 5.6 | 320×234 |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| A070FW03 V4 | AUO | 7.0 | 480×234 |
| AT056TN03 | Innolux | 5.6 | 320×234 |
| CLAA070WA03 | CPT | 7.0 | 480×234 |
| LB070W02-TMJ2 | LG Display | 7.0 | 480×234 |
| LQ050A3AD01 | SHARP | 5.0 | 320×234 |
| PA064DS1 | E Ink | 6.4 | 320×234 |
| PW070DS1T2 | E Ink | 7.0 | 480×234 |
