| PartNumber | NL8060BC26-15 |
| Marca | NLT |
| mărimea | 10.4 |
| Aplicație | NBPC |
| Rezoluţie | 800×600 |
| Compoziţie | LCM |
| Luminozitate | 100 |
| CR | 150:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | NEC |
| model de panou | NL8060BC26-15 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.4 inch |
| rezoluţie | 800(RGB)×600 , SVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 211.2×158.4 mm |
| contur | 237.8×170×6 mm |
| suprafaţă | Antireflection |
| luminozitatea | 100 cd/m² (Typ.) |
| Raport de contrast | 150:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193140% |
| timp de raspuns | TBD |
| unghi de vedere | 50/50/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (1 ch, 6-bit), 14 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
