| PartNumber | NL8048BC21-03F |
| Marca | NLT |
| mărimea | 8.0 |
| Aplicație | Industrial Outdoor H |
| Rezoluţie | 800×480 |
| Compoziţie | a-Si TFT-LCD , LCM |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca | NLT |
| dimensiunea diagonalei | 8.0 inch |
| format de pixeli | 800(RGB)×480 [WVGA] 116PPI |
| Zonă activă | 174(H)×104.4(V) mm |
| zona rama | - |
| luminanţă | 1000 cd/m² (Typ.) |
| direcția vizualizării | Symmetry |
| unghi de vedere | 88/88/88/88 (Typ.)(CR≥10) |
| culoare suport | 262K/16.7M 72% NTSC |
| greutate | 225g |
| rata de cadre | 60Hz |
| tipul de interfață | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| alimentare electrică | 3.3V (Typ.) |
| mediu inconjurator | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
| model | NL8048BC21-03F |
| tip | a-Si TFT-LCD , LCM |
| configurație | RGB Vertical Stripe |
| contur dim. | 192(H)×122(V) mm |
| tratament | Antiglare |
| Raport de contrast | 1000:1 (Typ.) (TM) |
| timp de raspuns | 20 (Typ.)(Tr+Td) |
| mod de operare | SFT, Normally Black, Transmissive |
| sursă de lumină | WLED |
| proiectat pentru | Industrial Outdoor High Brightness |
| panou tactil | Without |
