| PartNumber | NL6448BC33-49 |
| Marca | NLT |
| mărimea | 10.4 |
| Aplicație | IA |
| Rezoluţie | 640×480 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 300:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | TTL |
| marca panoului | NEC |
| model de panou | NL6448BC33-49 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.4 inch |
| rezoluţie | 640(RGB)×480 , VGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 211.2×158.4 mm |
| contur | 243×185.1×11 mm |
| suprafaţă | Antiglare, Hard coating (2H) |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 300:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193145% |
| timp de raspuns | 10/40 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/40/70 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit), 31 pins |
| tensiune de intrare | 3.3/5.0V (Typ.) |
| aplicarea | IA |
| NL6448AC33-18A | NLT | 10.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
| NL6448BC20-08E | NLT | 6.5 | 640×480 |
| NL6448BC20-20 | NLT | 6.5 | 640×480 |
| NL6448BC26-09 | NLT | 8.4 | 640×480 |
| NL6448BC26-17 | NLT | 8.4 | 640×480 |
| NL6448BC33-49 | NLT | 10.4 | 640×480 |
| NL6448BC33-53 | NLT | 10.4 | 640×480 |
| NL6448BC33-70D | NLT | 10.4 | 640×480 |
| NL6448BC33-74 | NLT | 10.4 | 640×480 |
| AM-800600M3TNQW-01H-F | AMPIRE | 8.4 | 800×600 |
| DLC1010DZG-T-8 | Other | 10.1 | 1280×800 |
| EL160.80.50 IN | Lumineq | 3.5 | 160×80 |
| HSD190MEN4-A03 | HannStar | 19.0 | 1280×1024 |
| LM085YB1T01 | SHARP | 8.5 | 800×480 |
| LQ104V1DG81 | SHARP | 10.4 | 640×480 |
| LQ10D41 | SHARP | 10.4 | 640×480 |
| LT084AC27900 | TOSHIBA | 8.4 | 800×600 |
| M190EG01 V0 | AUO | 19.0 | 1280×1024 |
| NL10276BC30-18 | NLT | 15.0 | 1024×768 |
