| PartNumber | N156BGA-EB3 |
| Marca | Innolux |
| mărimea | 15.6 |
| Aplicație | Laptop |
| Rezoluţie | 1366×768 |
| Compoziţie | a-Si TFT-LCD, LCM |
| Luminozitate | |
| CR | 600:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | eDP |
| marca | Innolux |
| model | N156BGA-EB3 (CMN15FD) |
| dimensiunea diagonalei | 15.6 inch |
| tip | a-Si TFT-LCD, LCM |
| format de pixeli | 1366(RGB)×768 [WXGA] 100PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 344.232(H)×193.536(V) mm |
| contur dim. | 350.73(H)×216.56(V) ×3.2(D) mm |
| zona rama | - |
| tratament | Glare (Haze 0%), Hard coating (3H) |
| luminanţă | 220 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) (TM) |
| direcția vizualizării | 6 o'clock |
| timp de raspuns | 3/7 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/20/45 (Typ.)(CR≥10) |
| mod de operare | TN, Normally White, Transmissive |
| culoare suport | 262K 45% NTSC |
| sursă de lumină | WLED , 15K hours , With LED Driver |
| stilul formei | Slim (PCBA Flat, T≤3.2mm) |
| proiectat pentru | Laptop |
| rata de cadre | 60Hz |
| panou tactil | Without |
| tipul de interfață | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| alimentare electrică | 3.3V (Typ.) |
| mediu inconjurator | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
