| PartNumber | N156BGE-EB1 |
| Marca | Innolux |
| mărimea | 15.6 |
| Aplicație | NBPC |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 220 |
| CR | 600:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | eDP |
| marca panoului | CHIMEI INNOLUX |
| model de panou | N156BGE-EB1 8 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 15.6 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 344.232×193.536 mm |
| contur | 359.5×222.3×3.25 mm |
| stilul formei | Slim (PCBA Flat, Depth ≤3.2mm) |
| suprafaţă | Glare (Haze 0%), Hard coating (3H) |
| luminozitatea | 220 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193145% |
| timp de raspuns | 3/8 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | eDP (1 Lane), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| N156B6-L04 | Innolux | 15.6 | 1366×768 |
| N156B6-L0A | Innolux | 15.6 | 1366×768 |
| N156B6-L0B | Innolux | 15.6 | 1366×768 |
| N156BGE-E42 | Innolux | 15.6 | 1366×768 |
| N156BGE-EA1 | Innolux | 15.6 | 1366×768 |
| N156BGE-EB1 | Innolux | 15.6 | 1366×768 |
| N156BGE-L21 | Innolux | 15.6 | 1366×768 |
| N156BGE-L52 | Innolux | 15.6 | 1366×768 |
| N156BGE-L62 | Innolux | 15.6 | 1366×768 |
| N156BGK-E33 | Innolux | 15.6 | 1366×768 |
| LP141WP1-TLA2 | LG Display | 14.1 | 1440×900 |
| LP150X05-A2C1 | LG Display | 15.0 | 1024×768 |
| LQ106K1LA01C | SHARP | 10.6 | 1280×768 |
| LTD121EW7V | TOSHIBA | 12.1 | 1280×800 |
| LTN140AT07-B01 | Samsung | 14.0 | 1366×768 |
| LTN156AT17-D01 | Samsung | 15.6 | 1366×768 |
| N140FGE-LA2 | Innolux | 14.0 | 1600×900 |
| N156BGE-L11 | Innolux | 15.6 | 1366×768 |
| TM121XG-02L10 | SANYO | 12.1 | 1024×768 |
| VVX16T020G00 | Panasonic | 15.5 | 2880×1620 |
