| PartNumber | N154I6-L03 |
| Marca | Innolux |
| mărimea | 15.4 |
| Aplicație | NBPC |
| Rezoluţie | 1280×800 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | CMO |
| model de panou | N154I6-L03 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 15.4 inch |
| rezoluţie | 1280(RGB)×800 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 331.2×207 mm |
| contur | 344×222×6.2 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | Glare (Haze 0%), Hard coating (3H) |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 3/5 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 8S6PWLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 6-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| LP154WE2-TLA3 | LG Display | 15.4 | 1680×1050 |
| N154I2-L01 | Innolux | 15.4 | 1280×800 |
| N154I2-L02 | Innolux | 15.4 | 1280×800 |
| N154I2-L05 | Innolux | 15.4 | 1280×800 |
| N154I3-L03 | Innolux | 15.4 | 1280×800 |
| N154I4-L03 | Innolux | 15.4 | 1280×800 |
| N154I4-L04 | Innolux | 15.4 | 1280×800 |
| N154I5-L02 | Innolux | 15.4 | 1280×800 |
| N154I6-L03 | Innolux | 15.4 | 1280×800 |
| TX39D80VC1GAA | KOE | 15.4 | 1280×800 |
| CLAA154WA05A | CPT | 15.4 | 1280×800 |
| LP133WH1-TLA3 | LG Display | 13.3 | 1366×768 |
| LP133WX2-TLC1 | LG Display | 13.3 | 1280×800 |
| LP141X2 | LG Display | 14.1 | 1024×768 |
| LP156WD1-TLB4 | LG Display | 15.6 | 1600×900 |
| LT121DEVPK00 | TOSHIBA | 12.1 | 1280×800 |
| LTD121EDFN | TOSHIBA | 12.1 | 1024×768 |
| N133HSE-EB2 | Innolux | 13.3 | 1920×1080 |
| N184H4-L04 | Innolux | 18.4 | 1920×1080 |
| QD15TL04 Rev.04 | QDI | 15.4 | 1280×800 |
