| PartNumber | TX39D80VC1GAA |
| Marca | KOE |
| mărimea | 15.4 |
| Aplicație | NBPC |
| Rezoluţie | 1280×800 |
| Compoziţie | LCM |
| Luminozitate | 480 |
| CR | 600:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | HITACHI |
| model de panou | TX39D80VC1GAA |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 15.4 inch |
| rezoluţie | 1280(RGB)×800 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 331.2×207 mm |
| contur | 344×225 mm |
| suprafaţă | Glare (Haze 0%) |
| luminozitatea | 480 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Min.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 50 (Typ.)(Tr+Td) |
| unghi de vedere | |
| frecvență | 60Hz |
| tip lampa | 2 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (1 ch, 6-bit) |
| tensiune de intrare | 3.3V (Typ.) |
| rohs: | |
| aplicarea | NBPC |
