| PartNumber | LP154W01-TLAD |
| Marca | LG Display |
| mărimea | 15.4 |
| Aplicație | NBPC |
| Rezoluţie | 1280×800 |
| Compoziţie | LCM |
| Luminozitate | 170 |
| CR | 300:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | LG.Philips LCD |
| model de panou | LP154W01-TLAD 16 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 15.4 inch |
| rezoluţie | 1280(RGB)×800 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 331.2×207 mm |
| contur | 344×243.5×6.5 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 170 cd/m² (Typ.) |
| Raport de contrast | 300:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193145% |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (1 ch, 6-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| LP154W01-TLA2 | LG Display | 15.4 | 1280×800 |
| LP154W01-TLE5 | LG Display | 15.4 | 1280×800 |
| LP154W02-B1K6 | LG Display | 15.4 | 1680×1050 |
| LP154WE2-TLB1 | LG Display | 15.4 | 1680×1050 |
| LP154WE3-TLA1 | LG Display | 15.4 | 1680×1050 |
| LP154WX4-TLA1 | LG Display | 15.4 | 1280×800 |
| LP154WX4-TLB2 | LG Display | 15.4 | 1280×800 |
| LP154WX4-TLB4 | LG Display | 15.4 | 1280×800 |
| LP154WX4-TLCB | LG Display | 15.4 | 1280×800 |
| LP154WX5-TLB2 | LG Display | 15.4 | 1280×800 |
| B140XTN01.3 | AUO | 14.0 | 1366×768 |
| B156HW01 V4 | AUO | 15.6 | 1920×1080 |
| B170PW03 V4 | AUO | 17.0 | 1440×900 |
| LP133WX1-TLC1 | LG Display | 13.3 | 1280×800 |
| LP140WH4-TLA1 | LG Display | 14.0 | 1366×768 |
| LP154WU1-A1K1 | LG Display | 15.4 | 1920×1200 |
| LTD121KX6B | TOSHIBA | 12.1 | 1280×800 |
| LTN150XG-L05 | Samsung | 15.0 | 1024×768 |
| LTN154BT07-S01 | Samsung | 15.4 | 1440×900 |
| TX39D80VC1GAA | KOE | 15.4 | 1280×800 |
