| PartNumber | M238DAN01.1 Q0 |
| Marca | AUO |
| mărimea | 23.8 |
| Aplicație | DMPC |
| Rezoluţie | 2560×1440 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | M238DAN01.1 Q0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 23.8 inch |
| rezoluţie | 2560(RGB)×1440 , Quad-HD |
| modul de afișare | AHVA, Normally Black, Transmissive |
| Zonă activă | 526.85×296.35 mm |
| contur | 534.74×213.26×12.3 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), sRGB100% |
| timp de raspuns | 14 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 20S4PWLEDWithout Driver |
| interfață de semnal | LVDS (4 ch, 8-bit), 92 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | DMPC |
| LM238WF1-SLE1 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSG2 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSK1 | LG Display | 23.8 | 1920×1080 |
| LM238WF4-SSA1 | LG Display | 23.8 | 1920×1080 |
| LM238WR1-SLA1 | LG Display | 23.8 | 3840×2160 |
| LM238WR2-SLA1 | LG Display | 23.8 | 3840×2160 |
| M238DAN01.1 Q0 | AUO | 23.8 | 2560×1440 |
| M238HAN01.0 | AUO | 23.8 | 1920×1080 |
| MV238FHM-N10 | BOE | 23.8 | 1920×1080 |
| MV238QUM-N20 | BOE | 23.8 | 3840×2160 |
| HR270WU1-200 | BOE | 27.0 | 1920×1080 |
| HT170E02-100 | BOE | 17.0 | 1280×1024 |
| LM185TT2A | PANDA | 18.5 | 1366×768 |
| LTM170EU-L11 | Samsung | 17.0 | 1280×1024 |
| LTM230HT03 | Samsung | 23.0 | 1920×1080 |
| M185XW01 V4 | AUO | 18.5 | 1366×768 |
| M240HW02 V7 | AUO | 24.0 | 1920×1080 |
| M270HHF-L10 | Innolux | 27.0 | 1920×1080 |
| MT190EN02 V.W | Innolux | 19.0 | 1280×1024 |
| MT230DW01 V.0 | Innolux | 23.0 | 1920×1080 |
