| PartNumber | M090AWA5 R0 |
| Marca | IVO |
| mărimea | 9.0 |
| Aplicație | Outdoor High Brightn |
| Rezoluţie | 1280×720 |
| Compoziţie | LCM, a-Si TFT-LCD |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | 7S4P |
| Interfață | |
| producător | IVO |
| numele modelului | M090AWA5 R0 |
| marimea ecranului | 9.0 inch |
| tipul de ecran | LCM, a-Si TFT-LCD |
| numărul de pixeli | 1280(RGB)×720 (WXGA) 163PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 198.72 × 111.78 (H×V) |
| contur (mm) | 212.2 × 127.5 × 10.5 (H×V×D) |
| zona rama (mm) | 201.72 × 114.78 (H×V) |
| tratament | Antiglare, Hard coating (3H), Reflection 6.0% (Max.) |
| luminanţă | 880 cd/m² (Typ.) |
| Raport de contrast | 1000 : 1 (Typ.) (TM) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10) |
| raspuns | 30 (Typ.)(Tr+Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | IPS, Normally Black, Transmissive |
| adâncimea culorii | 16.7M 70% NTSC |
| lumina de fundal | 7S4P WLED , 15K hours , No Driver |
| masa | 335g (Max.) |
| folosit pentru | Outdoor High Brightness Automotive Display |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
