| PartNumber | LTP280QV-E01 |
| Marca | Samsung |
| mărimea | 2.8 |
| Aplicație | MPH |
| Rezoluţie | 240×320 |
| Compoziţie | LCM |
| Luminozitate | 110 |
| CR | 150:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SAMSUNG |
| model de panou | LTP280QV-E01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 2.8 inch |
| rezoluţie | 240(RGB)×320 , QVGA |
| modul de afișare | TN, Normally White, Transflective |
| Zonă activă | 43.2×57.6 mm |
| contur | 52.9×71.7×4.75 mm |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 110 cd/m² (Typ.) |
| Raport de contrast | 150:1 (Typ.)(Transmissive)6:1 (Typ.)(Reflective) |
| culorile afișajului | 262K (6-bit), CIE193130% |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 50/40/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 6S1PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit), 61 pins |
| tensiune de intrare | 3.3/5.0/15/-10V (Typ.)(DVDD/AVDD/VON/VOFF) |
| aplicarea | MPH |
