| PartNumber | LQ047K3SX06 |
| Marca | SHARP |
| mărimea | 4.7 |
| Aplicație | MPH |
| Rezoluţie | 720×1280 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | SHARP |
| model de panou | LQ047K3SX06 |
| tip panou | IGZO TFT-LCD , LCM |
| dimensiunea panoului | 4.7 inch |
| rezoluţie | 720(RGB)×1280 , WXGA |
| modul de afișare | New Mode2, Normally Black, Transmissive |
| Zonă activă | 58.104×103.296 mm |
| contur | 61.05×112.09×1.52 mm |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193170% |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 10S1PWLEDWithout Driver |
| interfață de semnal | MIPI (4 data lanes), 40 pins |
| tensiune de intrare | 1.8/5.0/-5.0V (Typ.)(IOVCC/AVDD/AVEE) |
| aplicarea | MPH |
