| PartNumber | LTM190EX-L05 |
| Marca | Samsung |
| mărimea | 19.0 |
| Aplicație | DMPC |
| Rezoluţie | 1280×1024 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 700:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | SAMSUNG |
| model de panou | LTM190EX-L05 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 19.0 inch |
| rezoluţie | 1280(RGB)×1024 , SXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 376.32×301.056 mm |
| contur | 396×324×17 mm |
| suprafaţă | Glare (Haze 0%), Hard coating (3H) |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 700:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 1.7/6.3 (Typ.)(Tr/Td) |
| unghi de vedere | 75/75/75/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (2 ch, 8-bit), 30 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | DMPC |
| LTM190BT07 | Samsung | 19.0 | 1440×900 |
| LTM190E1-L03 | Samsung | 19.0 | 1280×1024 |
| LTM190E4-L02 | Samsung | 19.0 | 1280×1024 |
| LTM190E4-L03 | Samsung | 19.0 | 1280×1024 |
| LTM190ET01 | Samsung | 19.0 | 1280×1024 |
| LTM190EX-L01 | Samsung | 19.0 | 1280×1024 |
| LTM190EX-L21 | Samsung | 19.0 | 1280×1024 |
| LTM190EX-L31 | Samsung | 19.0 | 1280×1024 |
| LTM190M2-L31 | Samsung | 19.0 | 1440×900 |
| LTM190M2-L31(Glare) | Samsung | 19.0 | 1440×900 |
| CLAA170EA07 | CPT | 17.0 | 1280×1024 |
| LM190E09-TLB1 | LG Display | 19.0 | 1280×1024 |
| LM190E09-TLK1 | LG Display | 19.0 | 1280×1024 |
| LTM215HT04 | Samsung | 21.5 | 1920×1080 |
| M170EG01 VG | AUO | 17.0 | 1280×1024 |
| M201P1-L03 | Innolux | 20.1 | 1400×1050 |
| M236H3-LA2 | Innolux | 23.6 | 1920×1080 |
| M238DAN01.1 Q0 | AUO | 23.8 | 2560×1440 |
| MT190AW02 V.V | Innolux | 19.0 | 1440×900 |
| QD15XL13 Rev.01 | QDI | 15.0 | 1024×768 |
