| PartNumber | LTD104EDZS |
| Marca | TOSHIBA |
| mărimea | 10.4 |
| Aplicație | NBPC |
| Rezoluţie | 1024×768 |
| Compoziţie | LCM |
| Luminozitate | 245 |
| CR | 250:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | Toshiba Matsushita |
| model de panou | LTD104EDZS |
| tip panou | LTPS TFT-LCD , LCM |
| dimensiunea panoului | 10.4 inch |
| rezoluţie | 1024(RGB)×768 , XGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 210.4×157.8 mm |
| contur | 219.1×173.8×6.3 mm |
| suprafaţă | Antiglare |
| luminozitatea | 245 cd/m² (Typ.) |
| Raport de contrast | 250:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 40/40 (Max.)(Tr/Td) |
| unghi de vedere | |
| tip lampa | 9S4PWLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 6-bit), 25 pins |
| tensiune de intrare | 3.3V (Typ.) |
| rohs: | |
| aplicarea | NBPC |
