| PartNumber | LQ235D1LW03 |
| Marca | SHARP |
| mărimea | 23.6 |
| Aplicație | IA |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 5000:1 |
| Culori | 1.07B |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | SHARP |
| model de panou | LQ235D1LW03 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 23.6 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | UV2A, Normally Black, Transmissive |
| Zonă activă | 521.28×293.22 mm |
| contur | 554.8×319×21.4 mm |
| suprafaţă | Antiglare (Haze 2%), Hard coating (3H) |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 5000:1 (Typ.) |
| culorile afișajului | 1.07B (8-bit + Hi-FRC), CIE193172% |
| timp de raspuns | 4 (Typ.)(G to G) |
| unghi de vedere | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 120Hz |
| tip lampa | 13S4PWLEDWithout Driver |
| interfață de semnal | LVDS (4 ch, 10-bit), 92 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | IA |
