| PartNumber | LQ201U1LW31 |
| Marca | SHARP |
| mărimea | 20.1 |
| Aplicație | MD |
| Rezoluţie | 1600×1200 |
| Compoziţie | LCM |
| Luminozitate | 1000 |
| CR | 1000:1 |
| Culori | Grayscale |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | SHARP |
| model de panou | LQ201U1LW31 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 20.1 inch |
| rezoluţie | 1600(LCR)×1200 , UXGA |
| modul de afișare | ASV, Normally Black, Transmissive |
| Zonă activă | 408×306 mm |
| contur | 436×335×21.2 mm |
| suprafaţă | Antiglare, Hard coating (2H) |
| luminozitatea | 1000 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | Grayscale (8-bit) |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (2 ch, 8-bit), 30 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | MD |
