| PartNumber | LQ025A3DD01 |
| Marca | SHARP |
| mărimea | 2.5 |
| Aplicație | DSC |
| Rezoluţie | 480×240 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 400:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | Serial RGB |
| marca panoului | SHARP |
| model de panou | LQ025A3DD01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 2.5 inch |
| rezoluţie | 480×240 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 49.89×37.44 mm |
| contur | 58.85×43.55 mm |
| suprafaţă | Clear, Hard coating (2H) |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193135% |
| timp de raspuns | 30/50 (Typ.)(Tr/Td) |
| unghi de vedere | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 3S1PWLEDWithout Driver |
| interfață de semnal | Serial RGB (8-bit) + SPI, 39 pins |
| aplicarea | DSC |
| A025DN01 V9 | AUO | 2.5 | 320×240 |
| H245QBN02.0 | AUO | 2.5 | 240×432 |
| LH250Q01-TH02 | LG Display | 2.5 | 320×240 |
| LMS246GF06 | Samsung | 2.5 | 320×240 |
| LQ025A3DD01 | SHARP | 2.5 | 480×240 |
| LQ025Q3DW01 | SHARP | 2.5 | 320×240 |
| LTV250QV-F03 | Samsung | 2.5 | 320×240 |
| PA025XSF | E Ink | 2.5 | 480×234 |
| TD025THEB5 | TPO | 2.5 | 320×240 |
| TD025THEE6 | TPO | 2.5 | 640×240 |
| A015AN03 | AUO | 1.46 | 280×220 |
| A024CN02 VR | AUO | 2.4 | 480×234 |
| A027DN01 VR | AUO | 2.7 | 320×240 |
| A027DTN01.3 | AUO | 2.7 | 320×240 |
| A030DN01 VC | AUO | 3.0 | 320×240 |
| A030DN05 V0 | AUO | 3.0 | 320×240 |
| L3F04X-80300C | Epson | 0.48 | 1024×768 |
| LH250Q01-TH02 | LG Display | 2.5 | 320×240 |
| LQ035NC211 | Innolux | 3.5 | 320×240 |
| TM030CDH51-00 | Tianma | 3.0 | 320×240 |
