| PartNumber | LP123WQ1-SPA1 |
| Marca | LG Display |
| mărimea | 12.3 |
| Aplicație | Laptop |
| Rezoluţie | 2736×1824 |
| Compoziţie | LCM, a-Si TFT-LCD |
| Luminozitate | |
| CR | 1400:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | eDP |
| producător | LG Display |
| numele modelului | LP123WQ1-SPA1 |
| marimea ecranului | 12.3 inch |
| tipul de ecran | LCM, a-Si TFT-LCD |
| numărul de pixeli | 2736(RGB)×1824 267PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 259.78 × 173.19 (H×V) |
| contur (mm) | 265.38 × 183.49 × 4.25 (H×V×D) |
| zona rama (mm) | 262.18 × 175.59 (H×V) |
| tratament | Hard coating (3H) |
| luminanţă | - |
| Raport de contrast | 1400 : 1 (Typ.) (TM) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| raspuns | 27/46 (Max.)(Tr/Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | IPS, Normally Black, Transmissive |
| adâncimea culorii | 16.7M |
| lumina de fundal | WLED , 12K hours , No Driver |
| forma conturului | Slim (PCBA Bent, T≤3.0mm) |
| folosit pentru | Laptop |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| tipul semnalului | eDP (4 Lanes) , HBR2 (5.4G/lane) , Connector 60 pins |
| alimentare cu tensiune | 3.3V (Typ.) |
| max. evaluări | Storage Temp.: -20 ~ 70 °C Operating Temp.: 0 ~ 60 °C |
