| PartNumber | LM201U04-SL03 |
| Marca | LG Display |
| mărimea | 20.1 |
| Aplicație | DMPC |
| Rezoluţie | 1600×1200 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 700:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | LG.Philips LCD |
| model de panou | LM201U04-SL03 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 20.1 inch |
| rezoluţie | 1600(RGB)×1200 , UXGA |
| modul de afișare | S-IPS, Normally Black, Transmissive |
| Zonă activă | 408×306 mm |
| contur | 432×331.5×25.5 mm |
| suprafaţă | Antiglare (Haze 25%), Hard coating (3H) |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 700:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 7/9 (Typ.)(Tr/Td); 12 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (2 ch, 8-bit), 30 pins |
| tensiune de intrare | 20.0V (Typ.) |
| aplicarea | DMPC |
| LM201U02-A3C3 | LG Display | 20.1 | 1600×1200 |
| LM201U04-A3 | LG Display | 20.1 | 1600×1200 |
| LM201U04-A3K6 | LG Display | 20.1 | 1600×1200 |
| LM201U04-A3KC | LG Display | 20.1 | 1600×1200 |
| LM201U04-SL03 | LG Display | 20.1 | 1600×1200 |
| LM201U05-SLA1 | LG Display | 20.1 | 1600×1200 |
| LM201U05-SLA3 | LG Display | 20.1 | 1600×1200 |
| LM201U05-SLL1 | LG Display | 20.1 | 1600×1200 |
| LM201WE4-TLB2 | LG Display | 20.1 | 1680×1050 |
| M201EW02 V6 | AUO | 20.1 | 1680×1050 |
| HSD170ME13-A04 | HannStar | 17.0 | 1280×1024 |
| LM200WD3-TLC9 | LG Display | 20.0 | 1600×900 |
| LM230WF4-TLA1 | LG Display | 23.0 | 1920×1080 |
| LM230WU3-STC3 | LG Display | 23.0 | 1920×1200 |
| LTM170E8-L02 | Samsung | 17.0 | 1280×1024 |
| M170EG01 V7 | AUO | 17.0 | 1280×1024 |
| M220Z1-L09 | Innolux | 22.0 | 1680×1050 |
| M220Z1-P03 | Innolux | 22.0 | 1680×1050 |
| M270HTN01.0 | AUO | 27.0 | 1920×1080 |
| MT190AW02 V.4 | Innolux | 19.0 | 1440×900 |
