| PartNumber | LA123WF4-SR03 |
| Marca | LG Display |
| mărimea | 12.3 |
| Aplicație | Automotive Display |
| Rezoluţie | 1920×720 |
| Compoziţie | a-Si TFT-LCD, LCM |
| Luminozitate | |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | RSDS |
| marca | LG Display |
| model | LA123WF4-SR03 |
| dimensiunea diagonalei | 12.3 inch |
| tip | a-Si TFT-LCD, LCM |
| format de pixeli | 1920(RGB)×720 167PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 292.032(H)×109.512(V) mm |
| contur dim. | 310(H)×128(V) ×10.75(D) mm |
| zona rama | 296.03(H)×113.5(V) mm |
| tratament | Hard coating |
| luminanţă | 600 cd/m² (Min.) |
| Raport de contrast | 800:1 (Min.) (TM) |
| direcția vizualizării | Symmetry |
| timp de raspuns | 30 (Max.)(G to G); 25 (Typ.)(MPRT) |
| unghi de vedere | 89/89/89/89 (Min.)(CR≥10) |
| mod de operare | IPS, Normally Black, Transmissive |
| culoare suport | 16.7M 77% NTSC |
| sursă de lumină | WLED [11S4P] , 10K hours , W/O Driver |
| greutate | 385/400g (Typ./Max.) |
| proiectat pentru | Automotive Display |
| rata de cadre | 60Hz |
| panou tactil | Without |
| tipul de interfață | RSDS (2 Channel) , 110 pins FPC |
| alimentare electrică | 3.3/13.0V (Typ.)(VCC/VDD) |
| mediu inconjurator | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
