| PartNumber | HSD123KPW2-A10 |
| Marca | HannStar |
| mărimea | 12.3 |
| Aplicație | Automotive Display |
| Rezoluţie | 1920×720 |
| Compoziţie | LCM , a-Si TFT-LCD |
| Luminozitate | |
| CR | 1100:1 |
| Culori | 16.7M |
| Iluminare de fundal | 11S4P |
| Interfață | LVDS |
| producător | HannStar |
| marimea ecranului | 12.3 inch |
| numărul de pixeli | 1920(RGB)×720 167PPI |
| zona activa (mm) | 292.032 × 109.512 (H×V) |
| zona rama (mm) | 294.8 × 112.1 (H×V) |
| luminanţă | 850 cd/m² (Typ.) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| vedere buna la | Symmetry |
| adâncimea culorii | 16.7M 70% NTSC |
| masa | TBD |
| rată de reîmprospătare | 60Hz |
| tipul semnalului | LVDS (2 ch, 8-bit) , 50 pins Connector |
| alimentare cu tensiune | 3.3V (Typ.) |
| max. evaluări | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| numele modelului | HSD123KPW2-A10 |
| tipul de ecran | LCM , a-Si TFT-LCD |
| aranjament | RGB Vertical Stripe |
| contur (mm) | 308.1 × 130 × 15.6 (H×V×D) |
| tratament | Glare (Haze 0%) |
| Raport de contrast | 1100 : 1 (Typ.) (TM) |
| raspuns | 16/14 (Typ.)(Tr/Td) ms |
| modul de lucru | IPS Pro, Normally Black, Transmissive |
| lumina de fundal | 11S4P WLED , 30K hours , No Driver |
| folosit pentru | Automotive Display |
| touch screen | Without |
