| PartNumber | HSD104KXN1-A10 |
| Marca | HannStar |
| mărimea | 10.4 |
| Aplicație | Automotive Display |
| Rezoluţie | 1024×768 |
| Compoziţie | LCM, a-Si TFT-LCD |
| Luminozitate | |
| CR | 900:1 |
| Culori | 262K/16.2M |
| Iluminare de fundal | 4S8P |
| Interfață | |
| producător | HannStar |
| numele modelului | HSD104KXN1-A10 |
| marimea ecranului | 10.4 inch |
| tipul de ecran | LCM, a-Si TFT-LCD |
| numărul de pixeli | 1024(RGB)×768 (XGA) 123PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 211.2 × 158.4 (H×V) |
| contur (mm) | 236 × 174.3 × 7 (H×V×D) |
| zona rama (mm) | 213.2 × 160.4 (H×V) |
| tratament | Antiglare, Hard coating (3H) |
| luminanţă | 600 cd/m² (Typ.) |
| Raport de contrast | 900 : 1 (Typ.) (TM) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| raspuns | 30 (Typ.)(Tr+Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | IPS Pro, Normally Black, Transmissive |
| adâncimea culorii | 262K/16.2M |
| lumina de fundal | 4S8P WLED , 30K hours , No Driver |
| masa | 316g |
| folosit pentru | Automotive Display |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
