| PartNumber | LQ104V1LG92 |
| Marca | SHARP |
| mărimea | 10.4 |
| Aplicație | GM |
| Rezoluţie | 640×480 |
| Compoziţie | LCM |
| Luminozitate | 330 |
| CR | |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | SHARP |
| model de panou | LQ104V1LG92 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.4 inch |
| rezoluţie | 640(RGB)×480 , VGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 211.2×158.4 mm |
| contur | 240×179.2 mm |
| suprafaţă | |
| luminozitatea | 330 cd/m² (Typ.) |
| Raport de contrast | |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193172% |
| timp de raspuns | |
| unghi de vedere | |
| frecvență | 60Hz |
| tip lampa | 2 pcsCCFL |
| interfață de semnal | LVDS (1 ch, 8-bit) |
| aplicarea | GM |
