| PartNumber | HSD080JHW3-A11 |
| Marca | HannStar |
| mărimea | 8.0 |
| Aplicație | Outdoor High Brightn |
| Rezoluţie | 1280×720 |
| Compoziţie | , a-Si TFT-LCD |
| Luminozitate | |
| CR | 800:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | WLED |
| Interfață | |
| producător | HannStar |
| numele modelului | HSD080JHW3-A11 |
| marimea ecranului | 8.0 inch |
| tipul de ecran | , a-Si TFT-LCD |
| numărul de pixeli | 1280(RGB)×720 (WXGA) 184PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 176.64 × 99.36 (H×V) |
| contur (mm) | - |
| zona rama (mm) | - |
| tratament | Antireflection |
| luminanţă | 1000 cd/m² (Typ.) |
| Raport de contrast | 800 : 1 (Typ.) (TM) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| raspuns | 17/18 (Typ.)(Tr/Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | IPS Pro, Normally Black, Transmissive |
| adâncimea culorii | 262K/16.7M |
| lumina de fundal | WLED , No Driver |
| masa | - |
| folosit pentru | Outdoor High Brightness Automotive Display |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
