| PartNumber | H495TAN01.1 |
| Marca | AUO |
| mărimea | 5.0 |
| Aplicație | MPH |
| Rezoluţie | 720×1280 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 900:1 |
| Culori | 16.7M |
| Iluminare de fundal | No B/L |
| Interfață | |
| marca panoului | AUO |
| model de panou | H495TAN01.1 |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 720(RGB)×1280 , WXGA |
| modul de afișare | AHVA, Normally Black, Transmissive |
| Zonă activă | 61.688×109.632 mm |
| contur | 63.67×115.85×0.3 mm |
| suprafaţă | |
| adâncimea sticlei | 0.15+0.15 mm |
| transmisivitatea | 3.26% (Typ.)(with Polarizer) |
| Raport de contrast | 900:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193194% |
| timp de raspuns | 35 (Max.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| driver ic | COG Suggest HX8394-D21, N35521-DPAU, N35521S-DP8AU, OTM1284A-C6, OTM1287A-C8, R61318, RM68200 |
| aplicarea | MPH |
