| PartNumber | H381DLN01.0 |
| Marca | AUO |
| mărimea | 3.8 |
| Aplicație | MPH |
| Rezoluţie | 1080×1200 |
| Compoziţie | OLED |
| Luminozitate | 100 |
| CR | 3000:1 |
| Culori | 16.7M |
| Iluminare de fundal | self |
| Interfață | MIPI |
| marca panoului | AUO |
| model de panou | H381DLN01.0 |
| tip panou | AM-OLED , OLED |
| dimensiunea panoului | 3.8 inch |
| rezoluţie | 1080(RGB)×1200 |
| Zonă activă | 64.8×72 mm |
| contur | 67.6×78.95×1.24 mm |
| suprafaţă | |
| luminozitatea | 100 cd/m² (Typ.) |
| Raport de contrast | 3000 : 1 (Min.) |
| culorile afișajului | 16.7M (8-bit), CIE1931100% |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥480)(L/R/U/D) |
| driver ic | COG Built-in RM69071 |
| interfață de semnal | MIPI (4 data lanes), 39 pins |
| tensiune de intrare | 1.8/4.6/5.8/-2.9V (Typ.)(IOVCC/OVDD/AVDD/OVSS) |
| aplicarea | MPH |
