| PartNumber | ET104S0M-N11 |
| Marca | BOE |
| mărimea | 10.4 |
| Aplicație | Industrial |
| Rezoluţie | 800×600 |
| Compoziţie | a-Si TFT-LCD , LCM |
| Luminozitate | |
| CR | 800:1 |
| Culori | 262K/16.2M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca | BOE |
| dimensiunea diagonalei | 10.4 inch |
| format de pixeli | 800(RGB)×600 [SVGA] 96PPI |
| Zonă activă | 211.2(H)×158.4(V) mm |
| zona rama | 215(H)×162(V) mm |
| luminanţă | 350 cd/m² (Typ.) |
| direcția vizualizării | 12 o'clock |
| unghi de vedere | 80/80/65/75 (Typ.)(CR≥10) |
| culoare suport | 262K/16.2M 55% NTSC |
| greutate | 288g (Typ.) |
| rata de cadre | 60Hz |
| tipul de interfață | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| alimentare electrică | 3.3V (Typ.) |
| mediu inconjurator | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | ET104S0M-N11 |
| tip | a-Si TFT-LCD , LCM |
| configurație | RGB Vertical Stripe |
| contur dim. | 236(H)×176.9(V) ×5.9(D) mm |
| tratament | Antiglare (Haze 25%) |
| Raport de contrast | 800:1 (Typ.) (TM) |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| mod de operare | TN, Normally White, Transmissive |
| sursă de lumină | WLED , 30K hours , W/O Driver |
| proiectat pentru | Industrial |
| panou tactil | Without |
