EL320.240.36 HB SE

EL320.240.36 HB SE
EL320.240.36 HB SE
EL320.240.36 HB SE
EL320.240.36 HB SE thumb EL320.240.36 HB SE thumb EL320.240.36 HB SE thumb
Marca
PLANAR
mărimea
5.7
Aplicație
IA
Rezoluţie
320×240
Compoziţie
EL
Luminozitate
150
CR
90:1
Culori
Mono(Yellow)
Iluminare de fundal
self
Interfață
Parallel Data
In Stock
200
Specificații

PartNumber EL320.240.36 HB SE
MarcaPLANAR
mărimea5.7
AplicațieIA
Rezoluţie320×240
CompoziţieEL
Luminozitate150
CR90:1
CuloriMono(Yellow)
Iluminare de fundalself
InterfațăParallel Data
marca panouluiPLANAR
model de panouEL320.240.36 HB SE
tip panou EL , EL
dimensiunea panoului5.7 inch
rezoluţie320×240 , QVGA
Zonă activă115.1×86.3 mm
contur148.1×104.7 mm
suprafaţă
luminozitatea150 cd/m² (Typ.)
Raport de contrast90 : 1 (Typ.)
culorile afișajuluiMono(Yellow) (1-bit)
unghi de vedere89/89/89/89 (Typ.)(L/R/U/D)
frecvență120Hz
interfață de semnalParallel Data (1ch, 4-bit), 26 pins
tensiune de intrare5/12V (Typ.)(VL/VH)
aplicareaIA
Model de familie
EL320.240-FA3 CC Lumineq 4.9 320×240
EL320.240.36 Lumineq 5.7 320×240
EL320.240.36 ET CC Lumineq 5.7 320×240
EL320.240.36 HB Lumineq 5.7 320×240
EL320.240.36 HB NE PLANAR 5.7 320×240
EL320.240.36 HB NE CC PLANAR 5.7 320×240
EL320.240.36 HB SE PLANAR 5.7 320×240
EL320.240.36 IN Lumineq 5.7 320×240
EL320.240.36 IN AG Lumineq 5.7 320×240
EL320.240.36 LK Lumineq 5.7 320×240
