| PartNumber | DMF-50174ZNB-FW |
| Marca | Kyocera |
| mărimea | 5.7 |
| Aplicație | IA |
| Rezoluţie | 320×240 |
| Compoziţie | LCM |
| Luminozitate | 50 |
| CR | 4:1 |
| Culori | Monochrome |
| Iluminare de fundal | CCFL |
| Interfață | Parallel Data |
| marca panoului | OPTREX |
| model de panou | DMF-50174ZNB-FW |
| tip panou | STN-LCD , LCM |
| dimensiunea panoului | 5.7 inch |
| rezoluţie | 320×240 , QVGA |
| modul de afișare | STN, Transmissive |
| Zonă activă | 115.17×86.37 mm |
| contur | 174×115 mm |
| suprafaţă | |
| luminozitatea | 50 cd/m² (Typ.) |
| Raport de contrast | 4:1 (Typ.) |
| culorile afișajului | Monochrome |
| timp de raspuns | 100/360 (Typ.)(Tr/Td) |
| unghi de vedere | |
| frecvență | 70Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | Parallel Data (4-bit), 14 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | IA |
