| PartNumber | CLAA123PA02CW |
| Marca | CPT |
| mărimea | 12.3 |
| Aplicație | Industrial Outdoor H |
| Rezoluţie | 1440×540 |
| Compoziţie | a-Si TFT-LCD, LCM |
| Luminozitate | |
| CR | 700:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca | CPT |
| model | CLAA123PA02CW |
| dimensiunea diagonalei | 12.3 inch |
| tip | a-Si TFT-LCD, LCM |
| format de pixeli | 1440(RGB)×540 125PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 291.6(H)×109.35(V) mm |
| contur dim. | 312.9(H)×132.2(V) ×19.2(D) mm |
| zona rama | 294.8(H)×112.4(V) mm |
| tratament | Antiglare (Haze 25%) |
| luminanţă | 800 cd/m² (Typ.) |
| Raport de contrast | 700:1 (Typ.) (TM) |
| direcția vizualizării | 6 o'clock |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 60/60/50/60 (Typ.)(CR≥10) |
| mod de operare | TN, Normally White, Transmissive |
| culoare suport | 16.7M 70% NTSC |
| sursă de lumină | WLED [8S3P] , 30K hours , W/O Driver |
| greutate | 510g (Typ.) |
| proiectat pentru | Industrial Outdoor High Brightness Automotive Display |
| rata de cadre | 60Hz |
| panou tactil | Without |
| tipul de interfață | LVDS (1 ch, 8-bit) , 30 pins Connector |
| alimentare electrică | 3.3V (Typ.) |
| mediu inconjurator | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
