| PartNumber | CLAA098EP01XG |
| Marca | CPT |
| mărimea | 9.8 |
| Aplicație | |
| Rezoluţie | 1280×960 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 900:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | CPT |
| model de panou | CLAA098EP01XG |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 9.8 inch |
| rezoluţie | 1280(RGB)×960 , Quad-VGA |
| modul de afișare | HFFS, Normally Black, Transmissive |
| Zonă activă | 199.68×149.76 mm |
| suprafaţă | |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 900:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193150% |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 8-bit) + SPI |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| CLAA090NA02CW | CPT | 9.0 | 1024×600 |
| CLAA090NA06CW | CPT | 9.0 | 1024×600 |
| CLAA098EP01XG | CPT | 9.8 | 1280×960 |
| MD400F640PD5 | Panasonic | 9.8 | 640×400 |
| AMC162A | Other | 2.3 | 16×2 |
| LQ0DAS0749 | SHARP | 7.0 | 600×800 |
| LQ150X1LGN2A | SHARP | 15.0 | 1024×768 |
| LQ150X1LGN7 | SHARP | 15.0 | 1024×768 |
| LS013B4DN01 | SHARP | 1.35 | 96×96 |
| LS025Q1UC01 | SHARP | 2.5 | |
| LTD121KM1K | TOSHIBA | 12.1 | 1400×1050 |
| TD043MGEB1 | TPO | 4.3 | 800×480 |
| TFD58W40-F | TOSHIBA | 5.8 | |
| TY05001C0-40 V1 | Other | 5.0 | 800×480 |
