| PartNumber | CLAA080WQ05 XN |
| Marca | CPT |
| mărimea | 8.0 |
| Aplicație | Pad & Tablet Industr |
| Rezoluţie | 800×1280 |
| Compoziţie | LCM , a-Si TFT-LCD |
| Luminozitate | |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | 3S7P |
| Interfață | |
| producător | CPT |
| marimea ecranului | 8.0 inch |
| numărul de pixeli | 800(RGB)×1280 (WXGA) 188PPI |
| zona activa (mm) | 107.64 × 172.224 (H×V) |
| zona rama (mm) | - |
| luminanţă | 350 (Typ.)(cd/m²) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| vedere buna la | Symmetry |
| adâncimea culorii | 16.7M 58% NTSC |
| masa | 115g (Max.) |
| rată de reîmprospătare | 60Hz |
| numele modelului | CLAA080WQ05 XN |
| tipul de ecran | LCM , a-Si TFT-LCD |
| aranjament | RGB Vertical Stripe |
| contur (mm) | 114.6 × 184.7 × 4.56 (H×V×D) |
| tratament | Hard coating (3H) |
| Raport de contrast | 800 : 1 (Typ.) (TM) |
| modul de lucru | HFFS, Normally Black, Transmissive |
| raspuns | 30 (Typ.)(Tr+Td) ms |
| lumina de fundal | 3S7P WLED , 15K hours , No Driver |
| folosit pentru | Pad & Tablet Industrial |
| touch screen | Without |
