| PartNumber | CC500PV1D |
| Marca | PANDA |
| mărimea | 50 |
| Aplicație | TV Sets |
| Rezoluţie | 3840×2160 |
| Compoziţie | CELL, Oxide TFT-LC |
| Luminozitate | |
| CR | 5000:1 |
| Culori | 1.07B |
| Iluminare de fundal | No |
| Interfață | V-by-One |
| producător | PANDA |
| numele modelului | CC500PV1D |
| marimea ecranului | 50 inch |
| tipul de ecran | CELL, Oxide TFT-LCD |
| numărul de pixeli | 3840(RGB)×2160 (UHD) 89PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 1095.8 × 616.41 (H×V) |
| contur (mm) | 1106.84 × 628.01 × 1.37 (H×V×D) |
| zona rama (mm) | - |
| tratament | Antiglare, Hard coating (2H) |
| luminanţă | 0 cd/m² |
| Raport de contrast | 5000 : 1 (Typ.) (TM) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10) |
| raspuns | 8 (Typ.)(G to G) ms |
| vedere buna la | Symmetry |
| modul de lucru | UV2A, Normally Black, Transmissive |
| grosimea sticlei | 0.50+0.50 mm |
| transmisivitatea | 5.2% (Typ.)(with Polarizer) |
| adâncimea culorii | 1.07B 70% NTSC |
| lumina de fundal | No B/L |
| masa | 2.12Kgs (Typ.) |
| folosit pentru | TV Sets |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| lista de drivere ic | Built-in COF 12 source chips |
| tipul semnalului | V-by-One 8 lane , Connector 51 pins |
| alimentare cu tensiune | 12.0V (Typ.) |
| max. evaluări | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
