| PartNumber | C043GW01 V0 |
| Marca | AUO |
| mărimea | 4.3 |
| Aplicație | CNS |
| Rezoluţie | 400×234 |
| Compoziţie | LCM |
| Luminozitate | 600 |
| CR | 400:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | AUO |
| model de panou | C043GW01 V0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.3 inch |
| rezoluţie | 400(RGB)×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 94.8×52.65 mm |
| contur | 107.7×65.6 mm |
| suprafaţă | |
| luminozitatea | 600 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Min.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 15/20 (Typ.)(Tr/Td) |
| unghi de vedere | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLED |
| interfață de semnal | Parallel RGB (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.)(VDD) |
| aplicarea | CNS |
