| PartNumber | BT055FWM-N00 |
| Marca | BOE |
| mărimea | 5.5 |
| Aplicație | MPH |
| Rezoluţie | 480×854 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 700:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | BOE |
| model de panou | BT055FWM-N00 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.5 inch |
| rezoluţie | 480(RGB)×854 , FWVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 68.04×121.05 mm |
| contur | 72.34×130.86×2.3 mm |
| suprafaţă | Antiglare |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 700:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 5S2PWLEDWithout Driver |
| interfață de semnal | MIPI (2 data lanes), 25 pins |
| tensiune de intrare | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| aplicarea | MPH |
