| PartNumber | B133EW01 V3 |
| Marca | AUO |
| mărimea | 13.3 |
| Aplicație | NBPC |
| Rezoluţie | 1280×800 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 400:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | B133EW01 V3 2 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 13.3 inch |
| rezoluţie | 1280(RGB)×800 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 286.08×178.8 mm |
| contur | 299×195×5.5 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | Glare (Haze 0%), Hard coating (3H), Reflection 1.25% (Typ.) |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 12/4 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/25/35 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (1 ch, 6-bit), 20 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| B133EW01 V3 | AUO | 13.3 | 1280×800 |
| B133EW03 V0 | AUO | 13.3 | 1280×800 |
| B133EW03 V1 | AUO | 13.3 | 1280×800 |
| B133EW03 V2 | AUO | 13.3 | 1280×800 |
| B133EW04 V0 | AUO | 13.3 | 1280×800 |
| B133EW04 V4 | AUO | 13.3 | 1280×800 |
| B133EW05 V0 | AUO | 13.3 | 1280×800 |
| B133EW06 V0 | AUO | 13.3 | 1280×800 |
| B133EW07 V1 | AUO | 13.3 | 1280×800 |
| B133EW07 V2 | AUO | 13.3 | 1280×800 |
| LP101WH2-TLA2 | LG Display | 10.1 | 1366×768 |
| LP141X13-B1 | LG Display | 14.1 | 1024×768 |
| LP154WX5-TLC2 | LG Display | 15.4 | 1280×800 |
| LTN133AT17-H01 | Samsung | 13.3 | 1366×768 |
| LTN134AT01-001 | Samsung | 13.4 | 1366×768 |
| LTN154X3-L03 | Samsung | 15.4 | 1280×800 |
| N133BGE-E51 | Innolux | 13.3 | 1366×768 |
| N140B6-L02 | Innolux | 14.0 | 1366×768 |
| N156BGE-EA1 | Innolux | 15.6 | 1366×768 |
| VVX16T010J00 | Panasonic | 15.5 | 2880×1620 |
