| PartNumber | B121EW03 V8 |
| Marca | AUO |
| mărimea | 12.1 |
| Aplicație | NBPC |
| Rezoluţie | 1280×800 |
| Compoziţie | LCM |
| Luminozitate | 220 |
| CR | 400:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | B121EW03 V8 2 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 12.1 inch |
| rezoluţie | 1280(RGB)×800 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 261.12×163.2 mm |
| contur | 275.8×178×6.5 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | Glare (Haze 0%), Hard coating (3H), Reflection 4.3% (Typ.) |
| luminozitatea | 220 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193145% |
| timp de raspuns | 16 (Typ.)(Tr+Td) |
| unghi de vedere | 40/40/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (1 ch, 6-bit), 20 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| B121EW01 V0 | AUO | 12.1 | 1280×800 |
| B121EW01 V1 | AUO | 12.1 | 1280×800 |
| B121EW02 V0 | AUO | 12.1 | 1280×800 |
| B121EW03 V7 | AUO | 12.1 | 1280×800 |
| B121EW03 V9 | AUO | 12.1 | 1280×800 |
| B121EW09 V0 | AUO | 12.1 | 1280×800 |
| B121EW09 V4 | AUO | 12.1 | 1280×800 |
| B121EW10 V1 | AUO | 12.1 | 1280×800 |
| B121EW10 V2 | AUO | 12.1 | 1280×800 |
| B121EW13 V1 | AUO | 12.1 | 1280×800 |
| B150XG01 V7 | AUO | 15.0 | 1024×768 |
| B156XTN03.2 | AUO | 15.6 | 1366×768 |
| HN116WX1-203 | BOE | 11.6 | 1366×768 |
| LP171WX2-A4K1 | LG Display | 17.1 | 1440×900 |
| LP173WD1-TLN2 | LG Display | 17.3 | 1600×900 |
| LTD133EWCF | TOSHIBA | 13.3 | 1280×800 |
| LTM15C162 | TOSHIBA | 15.0 | 1600×1200 |
| LTN154X3-L03 | Samsung | 15.4 | 1280×800 |
| LTN170WU-L01 | Samsung | 17.0 | 1920×1200 |
| N173FGE-E23 | Innolux | 17.3 | 1600×900 |
