| PartNumber | B121EW02 V0 |
| Marca | AUO |
| mărimea | 12.1 |
| Aplicație | NBPC |
| Rezoluţie | 1280×800 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 300:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | B121EW02 V0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 12.1 inch |
| rezoluţie | 1280(RGB)×800 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 261.12×163.2 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 300:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 25 (Typ.)(Tr+Tf) |
| unghi de vedere | 65/65/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFL |
| interfață de semnal | LVDS (1 ch, 6-bit), 20 pins |
| rohs: | |
| aplicarea | NBPC |
| B121EW01 V0 | AUO | 12.1 | 1280×800 |
| B121EW01 V1 | AUO | 12.1 | 1280×800 |
| B121EW02 V0 | AUO | 12.1 | 1280×800 |
| B121EW03 V3 | AUO | 12.1 | 1280×800 |
| B121EW03 V6 | AUO | 12.1 | 1280×800 |
| B121EW03 V8 | AUO | 12.1 | 1280×800 |
| B121EW09 V3 HW0A | AUO | 12.1 | 1280×800 |
| B121EW10 V1 | AUO | 12.1 | 1280×800 |
| B121EW10 V2 | AUO | 12.1 | 1280×800 |
| B121EW13 V1 | AUO | 12.1 | 1280×800 |
| B140XTN03.5 | AUO | 14.0 | 1366×768 |
| B156HTB01.0 | AUO | 15.6 | 1920×1080 |
| B170PW02 V0 | AUO | 17.0 | 1440×900 |
| LP140WF3-SPD1 | LG Display | 14.0 | 1920×1080 |
| LP140WH1-TLA1 | LG Display | 14.0 | 1366×768 |
| LTN141AT08-001 | Samsung | 14.1 | 1280×800 |
| N141C1-L01 | Innolux | 14.1 | 1440×900 |
| N141I6-D11 | Innolux | 14.1 | 1280×800 |
| N156BGE-E21 | Innolux | 15.6 | 1366×768 |
| TX41D97VC1HAA | KOE | 16.1 | 1400×1050 |
