| PartNumber | LP171WX2-A4K1 |
| Marca | LG Display |
| mărimea | 17.1 |
| Aplicație | NBPC |
| Rezoluţie | 1440×900 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 350:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | LG.Philips LCD |
| model de panou | LP171WX2-A4K1 3 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 17.1 inch |
| rezoluţie | 1440(RGB)×900 , WXGA+ |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 367.2×229.5 mm |
| contur | 382.2×244.5×6.5 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | Glare (Haze 0%), Hard coating (2H), Antireflection |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 350:1 (Min.) |
| culorile afișajului | 262K (6-bit), CIE193145% |
| timp de raspuns | 6/19 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/50/50 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (2 ch, 6-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| LP171WE2-TLA2 | LG Display | 17.1 | 1680×1050 |
| LP171WP4-TLB3 | LG Display | 17.1 | 1440×900 |
| LP171WP4-TLR1 | LG Display | 17.1 | 1440×900 |
| LP171WU1-A4K2 | LG Display | 17.1 | 1920×1200 |
| LP171WU1-A4K3 | LG Display | 17.1 | 1920×1200 |
| LP171WU1-TLA7 | LG Display | 17.1 | 1920×1200 |
| LP171WU5-TLA1 | LG Display | 17.1 | 1920×1200 |
| LP171WU5-TLB1 | LG Display | 17.1 | 1920×1200 |
| LP171WX2-A4K1 | LG Display | 17.1 | 1440×900 |
| LP171WX2-TLB1 | LG Display | 17.1 | 1440×900 |
| B133XW04 V0 | AUO | 13.3 | 1366×768 |
| B141XN03 V0 | AUO | 14.1 | 1024×768 |
| LP133WH2-SPA2 | LG Display | 13.3 | 1366×768 |
| LP156WH4-TLN2 | LG Display | 15.6 | 1366×768 |
| LP171WP9-TLB3 | LG Display | 17.1 | 1440×900 |
| LP201WE1-TLA1 | LG Display | 20.1 | 1680×1050 |
| LTN141AT08-001 | Samsung | 14.1 | 1280×800 |
| LTN141W1-L04 | Samsung | 14.1 | 1280×800 |
| LTN141XF-L03 | Samsung | 14.1 | 1024×768 |
| N173O6-L02 | Innolux | 17.3 | 1600×900 |
