| PartNumber | ASI545FB01-0 |
| Marca | Samsung |
| mărimea | 55 |
| Aplicație | DID |
| Rezoluţie | 1920×1080 |
| Compoziţie | OLED |
| Luminozitate | 500 |
| CR | |
| Culori | 1.07B |
| Iluminare de fundal | self |
| Interfață | LVDS |
| marca panoului | SAMSUNG |
| model de panou | ASI545FB01-0 |
| tip panou | TOLED , OLED |
| dimensiunea panoului | 55 inch |
| rezoluţie | 1920×1080(RGB) , FHD |
| Zonă activă | 1209.6×680.4 mm |
| contur | 1219.4×697 mm, Videowall Seam 9.8 mm |
| suprafaţă | Hard coating (2H), Antireflection |
| luminozitatea | 500 cd/m² (Typ.) |
| Raport de contrast | |
| culorile afișajului | 1.07B (10-bit), CIE1931100% |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | LVDS (2 ch, 10-bit), 51 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | DID |
| ASI545FB01-0 | Samsung | 55 | 1920×1080 |
| HV550WUP-200 | BOE | 55 | 1920×1080 |
| LC550EUB-SCA1 | LG Display | 55 | 1920×1080 |
| LC550EUD-SCA1 | LG Display | 55 | 1920×1080 |
| LC550EUG-PEF1 | LG Display | 55 | 1920×1080 |
| LTA550HJ05 | Samsung | 55 | 1920×1080 |
| LTI550HN03 | Samsung | 55 | 1920×1080 |
| T546HW02 V1 | AUO | 55 | 1920×1080 |
| T550QVD01.0 | AUO | 55 | 3840×2160 |
| V546H1-LS1 | Innolux | 55 | 1920×1080 |
| ASI545FB01-0 | Samsung | 55 | 1920×1080 |
| LD470DXS-SCA1 | LG Display | 47 | 1366×768 |
| LD470DXS-SCB1 | LG Display | 47 | 1366×768 |
| LD550DUN-THB3 | LG Display | 55 | 1920×1080 |
| LTI460HN01 | Samsung | 46 | 1920×1080 |
| LTI460HN07 | Samsung | 46 | 1920×1080 |
| LTI460HN09 | Samsung | 46 | 1920×1080 |
| LTI460HN10 | Samsung | 46 | 1920×1080 |
| LTI460HN11 | Samsung | 46 | 1920×1080 |
| LTI550HN14 | Samsung | 55 | 1920×1080 |
