| PartNumber | AM480272H3TMQW-TW2H |
| Marca | AMPIRE |
| mărimea | 4.3 |
| Aplicație | IA |
| Rezoluţie | 480×272 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 250:1 |
| Culori | 65K/262K |
| Iluminare de fundal | WLED |
| Interfață | CPU |
| marca panoului | AMPIRE |
| model de panou | AM480272H3TMQW-TW2H |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.3 inch |
| rezoluţie | 480(RGB)×272 , WQVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 95.04×53.856 mm |
| contur | 105.5×67.2×7.91 mm |
| suprafaţă | |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 250:1 (Typ.) |
| culorile afișajului | 65K/262K |
| timp de raspuns | 15/35 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/35/55 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 7S1PWLEDWithout Driver |
| interfață de semnal | 8/9/16/18-bit 6800/8080 parallel, 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
