| PartNumber | AM-19201200CTZQW-00 |
| Marca | AMPIRE |
| mărimea | 10.1 |
| Aplicație | Industrial Outdoor H |
| Rezoluţie | 1920×1200 |
| Compoziţie | LCM, a-Si TFT-LCD |
| Luminozitate | |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | |
| producător | AMPIRE |
| numele modelului | AM-19201200CTZQW-00 |
| marimea ecranului | 10.1 inch |
| tipul de ecran | LCM, a-Si TFT-LCD |
| numărul de pixeli | 1920(RGB)×1200 (WUXGA) 225PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 216.576 × 135.36 (H×V) |
| contur (mm) | 244.8 × 155.3 × 7 (H×V×D) |
| luminanţă | 1000 cd/m² (Typ.) |
| Raport de contrast | 800 : 1 (Typ.) (TM) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| raspuns | 25 (Typ.)(Tr+Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | AHVA, Normally Black, Transmissive |
| adâncimea culorii | 16.7M 49% NTSC |
| lumina de fundal | WLED , 50K hours , With LED Driver |
| masa | - |
| folosit pentru | Industrial Outdoor High Brightness |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| Storage Temp.: -20 ~ 65 °C Operating Temp.: -20 ~ 65 °C |
