| PartNumber | AG-320240A4FIQW-K9H-S(N)(R) |
| Marca | AMPIRE |
| mărimea | 5.7 |
| Aplicație | IA |
| Rezoluţie | 320×240 |
| Compoziţie | LCM |
| Luminozitate | |
| CR | |
| Culori | Monochrome |
| Iluminare de fundal | WLED |
| Interfață | CPU |
| marca panoului | AMPIRE |
| model de panou | AG-320240A4FIQW-K9H-S(N)(R) |
| tip panou | FSTN-LCD , LCM |
| dimensiunea panoului | 5.7 inch |
| rezoluţie | 320×240 , QVGA |
| modul de afișare | STN, Transflective |
| Zonă activă | 115.185×86.385 mm |
| contur | 167×104.7×14.5 mm |
| suprafaţă | |
| luminozitatea | |
| Raport de contrast | |
| culorile afișajului | Monochrome |
| timp de raspuns | 200/200 (Typ.)(Tr/Td) |
| unghi de vedere | 30/30/35/30 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 1S6PWLEDWithout Driver |
| interfață de semnal | 8-bit 6080/8080 parallel, 24 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | IA |
