| PartNumber | AA070TA01 |
| Marca | Mitsubishi |
| mărimea | 7.0 |
| Aplicație | Industrial Outdoor H |
| Rezoluţie | 1280×768 |
| Compoziţie | a-Si TFT-LCD , LCM |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | WLED |
| Interfață | |
| marca panoului | Mitsubishi |
| dimensiunea panoului | 7.0" |
| rezoluţie | 1280(RGB)×768, WXGA, 214PPI |
| zona de afisare | 151.68(W)×91.01(H) mm |
| dimensiunea conturului | 169.8(W)×109.7(H) mm |
| luminozitatea | 1000 cd/m² (Typ.) |
| unghi de vedere | 88/88/88/88 (Typ.)(CR≥10) |
| cea mai bună vedere pe | Symmetry |
| culorile afișajului | 262K/16.7M 49% NTSC |
| frecvență | 60Hz |
| greutate | 200g (Typ.) |
| model de panou | AA070TA01 |
| tip panou | a-Si TFT-LCD , LCM |
| format de pixeli | RGB Vertical Stripe |
| deschiderea ramei | 155.1(W)×94.4(H) mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| Raport de contrast | 1000:1 (Typ.) (TM) |
| modul de afișare | SWV, Normally Black, Transmissive |
| timp de raspuns | 12/12 (Typ.)(Tr/Td) |
| tip lampa | WLED , 100K hours , With LED Driver |
| touch screen | Without |
| aplicarea | Industrial Outdoor High Brightness Automotive Display |
