| PartNumber | V460H1-L12 |
| Marca | Innolux |
| mărimea | 46 |
| Aplicație | LCTV |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM |
| Luminozitate | 380 |
| CR | 4000:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | CHIMEI INNOLUX |
| model de panou | V460H1-L12 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 46 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | Super MVA, Normally Black, Transmissive |
| Zonă activă | 1018.08×572.67 mm |
| contur | 1083×627 mm |
| suprafaţă | Antiglare (Haze 11%) |
| luminozitatea | 380 cd/m² (Typ.) |
| Raport de contrast | 4000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 8.5 (Typ.)(G to G) |
| unghi de vedere | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 12 pcsCCFLEmbedded (Balance board) |
| interfață de semnal | LVDS (2 ch, 8-bit), 51 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | LCTV |
| V460H1-L09 | Innolux | 46 | 1920×1080 |
| V460H1-L12 | Innolux | 46 | 1920×1080 |
| V460H1-LE3 | Innolux | 46 | 1920×1080 |
| V460H1-LH9 | Innolux | 46 | 1920×1080 |
| V460H1-LS1 | Innolux | 46 | 1920×1080 |
| V460H1-LS1 Rev.C6 | Innolux | 46 | 1920×1080 |
| V460H1-LS2 | Innolux | 46 | 1920×1080 |
| V460H1-LS2 Rev.C7 | Innolux | 46 | 1920×1080 |
| V460HK2-LS5 | Innolux | 46 | 1920×1080 |
| LC230EUE-SEA1 | LG Display | 23.0 | 1920×1080 |
| LC320DUN-SFR1 | LG Display | 31.5 | 1920×1080 |
| LC370EUN-SDV2 | LG Display | 37 | 1920×1080 |
| LC420EUF-FFP3 | LG Display | 42 | 1920×1080 |
| LC470DUE-FGA3 | LG Display | 47 | 1920×1080 |
| LC550EQE-PHF1 | LG Display | 55 | 3840×2160 |
| LTA320AP02 | Samsung | 31.5 | 1366×768 |
| LTZ320AB02 | Samsung | 31.5 | 1366×768 |
| T460HW04 V6 | AUO | 46 | 1920×1080 |
| T500HVN04.1 CELL | AUO | 50 | 1920×1080 |
