| PartNumber | TM057QDH01 |
| Marca | Tianma |
| mărimea | 5.7 |
| Aplicație | IA |
| Rezoluţie | 640×480 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | TIANMA |
| model de panou | TM057QDH01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.7 inch |
| rezoluţie | 640(RGB)×480 , VGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 115.2×86.4 mm |
| contur | 144×104.6×12.8 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193150% |
| timp de raspuns | 20 (Typ.)(Tr+Td) |
| unghi de vedere | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 7S3PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit), 33 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
| TM057KDH01 | Tianma | 5.7 | 320×240 |
| TM057KDH02 | Tianma | 5.7 | 320×240 |
| TM057KDH03 | Tianma | 5.7 | 320×240 |
| TM057KDH05 | Tianma | 5.7 | 320×240 |
| TM057KDHG03 | Tianma | 5.7 | 320×240 |
| TM057KDHG10 | Tianma | 5.7 | 320×240 |
| TM057QDH01 | Tianma | 5.7 | 640×480 |
| TM057QDHG02 | Tianma | 5.7 | 640×480 |
| TM057QDHG04 | Tianma | 5.7 | 640×480 |
| TM057QVHG01 | Tianma | 5.7 | 640×480 |
| AA065VE01 | Mitsubishi | 6.5 | 640×480 |
| G057VN01 V0 | AUO | 5.7 | 640×480 |
| G084SN05 V5 | AUO | 8.4 | 800×600 |
| LB104S04-TL01 | LG Display | 10.4 | 800×600 |
| LB121S03-TL03 | LG Display | 12.1 | 800×600 |
| LM32C041 | SHARP | 5.5 | 320×240 |
| LQ121S1DG21A | SHARP | 12.1 | 800×600 |
| LQ64D343R | SHARP | 6.4 | 640×480 |
| TM080VG-22L01 | SANYO | 8.0 | 640×480 |
| TX26D11VM1CAA | KOE | 10.4 | 640×480 |
