| PartNumber | TCG070WVLQGPNN-AN40 |
| Marca | Kyocera |
| mărimea | 7.0 |
| Aplicație | Industrial Outdoor H |
| Rezoluţie | 800×480 |
| Compoziţie | LCM , a-Si TFT-LCD |
| Luminozitate | |
| CR | 750:1 |
| Culori | 262K/16.2M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| producător | Kyocera |
| marimea ecranului | 7.0 inch |
| numărul de pixeli | 800(RGB)×480 (WVGA) 133PPI |
| zona activa (mm) | 152.4 × 91.44 (H×V) |
| zona rama (mm) | 154.4 × 93.4 (H×V) |
| luminanţă | 1000 cd/m² (Typ.) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| vedere buna la | Symmetry |
| adâncimea culorii | 262K/16.2M 50% NTSC |
| masa | 230g |
| rată de reîmprospătare | 60Hz |
| tipul semnalului | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| alimentare cu tensiune | 3.3V (Typ.) |
| max. evaluări | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
| numele modelului | TCG070WVLQGPNN-AN40 |
| tipul de ecran | LCM , a-Si TFT-LCD |
| aranjament | RGB Vertical Stripe |
| contur (mm) | 169.8 × 109.7 × 9.7 (H×V×D) |
| tratament | Antiglare |
| Raport de contrast | 750 : 1 (Typ.) (TM) |
| raspuns | 18/12 (Typ.)(Tr/Td) ms |
| modul de lucru | AWV, Normally Black, Transmissive |
| lumina de fundal | WLED , 70K hours , With LED Driver |
| folosit pentru | Industrial Outdoor High Brightness Automotive Display |
| touch screen | Without |
| CLAA070NJ07CW | CPT | 7.0 | 1024×600 |
| DLC0700OZG-T-1 | Other | 7.0 | 800×480 |
| G070Y3-T01 | Innolux | 7.0 | 800×480 |
| HSD070IFW1-B00 | HannStar | 7.0 | 1024×600 |
| LQ070T1LG01 | SHARP | 7.0 | 800×480 |
| LQ070T5GC01 | SHARP | 7.0 | |
| LQ070Y5DA02A | SHARP | 7.0 | 800×480 |
| Q070LRE-L81 | Innolux | 7.0 | 1024×600 |
| TCG070WVLBA-A00 | Kyocera | 7.0 | 800×480 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
